How it works:

The slurry flows horizontally through the bead mill from the inlet on the motor side of the grinding chamber.

During the process, the particles in slurry continuously collide, rub, shear and grind with the media to the target particle size.

Finally, the product of target particle size flow through the screen fixed on the rear of the grinding chamber.

Features:

Grinding the materials to nano-level (1μm-200 nm)

Used in the processing of almost all of the product that need to be ground to ultra-fine level and suitable for almost every viscosity.

Using grinding media of zirconia from 0.1 mm to 2.0 mm and several types of solvent, depending the product properties.

Various materials for product-wetted components to meet the different requirements, such as zirconia, polyurethane, alloy steel for rotor and polyurethane, zirconia, silicon carbide, stainless steel for inside layer of grinding chamber.

Optimized cooling layer equipped outside the grinding chamber, cooling coil beneath the sieve and the cooling device for the mechanical seal to control the temperature rise below 20 degrees.
